AX6000 Wi-Fi 6 2.5G Ethernet Gateway

The Zyxel EX5510-B0 Dual-Band Wireless AX Gigabit Ethernet Gateway supports dual-band wireless AX with 2.5 Giga Ethernet internet access to give you delightful wireless experiences in your ultra-connected home.

Download SOP of Plume Firmware Conversion

  • 5 GHz 4x4 ax
  • 2.4 GHz 4x4 ax
  • EasyMesh standards
  • 2.5GbE WAN
  • TR-069
  • CAF ll testing support
  • OPAL platform
  • Multiple SSIDs
  • Comprehensive QoS
Download resources

Lightning-fast next-generation technology

The Zyxel EX5510-B0 supports the 802.11ax (Wi-Fi 6) standard to offer lightning-fast throughputs of up to 6000 Mbps. The performance enables operators to provide UHD 4K/8K services to subscribers and hybrid high-throughput applications in homes for a true IoT lifestyle.


Maximize network capacity for more devices

Supported by revolutionary Orthogonal Frequency Division Multiple Access (OFDMA), the Zyxel EX5510-B Series improves average throughputs to considerably shorten latency and increase network efficiency.


CAF II performance testing support

The Zyxel EX5510-B0 supports optimized TR-143 protocol to facilitate FCC mandated CAF II performance testing.

TR-069 remote management

With the TR-069 standard management specifications, the Zyxel EX5510-B0 allows service providers to manage, configure, monitor and diagnose client devices remotely without interfering end users. This unique feature not only offers true “plug-and-play” experience but also reduces deployment complexity, and it also saves operating as well as maintenance costs for service providers.


Zyxel OPAL firmware realizes the flexibility and faster time to market

With same OPAL firmware trunk applied in Zyxel CPE, the EX5510-B0 inherits a rich, field-proven feature set including TR-069 and more. Service providers can expect the same user experience after they migrate to new devices. Furthermore, the lab qualification time can be greatly reduced by using the same OPAL firmware trunk. As a flexible software platform, OPAL, a modular software architecture and open framework, provides the flexibility for easy feature tailoring to assure all the application requests can be addressed.


Multi-Gig Internet access

The Zyxel EX5510-B0 supports one 2.5 Giga Ethernet WAN and four Gigabit LAN ports for multiple user connection in the area; and it also delivers wireless speeds of up to 4.8 Gbps on the 5 GHz band and 1.1 Gbps on 2.4 GHz.


Premium MPro Mesh™ for whole-home coverage

Featuring EasyMesh fully compliant Zyxel MPro Mesh™ Solutions, the Zyxel EX5510-B0 enhances your subscribers’ experience by providing self-adapting, easy-to-manage whole-home Wi-Fi coverage while reducing your service OPEX.


Unmatched Wi-Fi 6 savings! Our best Wi-Fi 6 at our best prices of the year.

System specifications

Wireless standards
  • IEEE 802.11 b/g/n/ax 2.4 GHz
  • IEEE 802.11 a/n/ac/ax 5 GHz
Wireless transfer rates
  • Transmit:
    • 802.11ax (2.4 GHz): up to 1148 Mbps
    • 802.11ax (5 GHz): up to 4804 Mbps
  • Auto channel selection
  • WMM
  • WPA2-PSK
  • Wireless output power management
  • Multiple SSID up to 4
  • Wi-Fi Protected Setup (WPS)
  • Intra-BSS traffic block
  • MAC address filtering
  • WPS 2.0
  • MPro Mesh™
  • IPv4 / IPv6 firewall (Stateful Packet Inspection)
  • Denial-of-Service (DoS) attack prevention
  • ICMP blocking
  • IPv4/IPv6
  • NAT
  • Port forwarding
  • WAN connection type: DHCP, PPPoE
  • DHCP Option 43/60/121/125
  • DHCP server on LAN
  • IGMP v2/v3
  • IGMP Proxy
  • Dynamic DNS
VPN Pass-through
  • PPTP
  • L2TP
  • IPSec
  • 802.1q tag/tag based VLAN
  • VLAN to ETH port mapping
  • Bridged/routed VLAN support
  • TR-069/TR-098/TR-181
  • Firmware upgrade through GUI/TR-069
  • 2-tier level access and administration

Hardware specifications

  • One 1/2.5GbE RJ-45 port
  • Four 1GbE RJ-45 ports
  • 2.4 GHz: 4x4 MIMO antenna array
  • 5 GHz: 4x4 MIMO antenna array
  • One USB 3.0 host
Status LEDs indicators
  • Power
  • Ethernet WAN
  • Internet
  • Wi-Fi 2.4G
  • Wi-Fi 5G
  • WPS
  • WPS
  • Reset
Power consumption
  • 12 V DC, 3.0 A
  • 36 Watt max

Physical specifications

  • Item dimensions (WxDxH): 118 x 120 x 225 mm (4.64” x 4.72” x 8.85”)
  • Item weight: 793 g (1.75 lb.)
  • Packing dimensions (WxDxH): 263 x 180 x 136 mm (10.35” x 7.08” x 5.35”)
  • Packing weight: 1387 g (3.06 lb.)

Environmental specifications

Operating Environment
  • Temperature: 0°C to 40°C (32°F to 104°F)
  • Humidity: 10% to 90% (Non-condensing)
Storage Environment
  • Temperature: -30°C to 70°C (-22°F to 158°F)
  • Humidity: 10% to 95% (Non-condensing)


  • FCC, IC

Package contents

  • Gigabit Ethernet Gateway
  • Power adapter
  • Ethernet cable
  • Quick start guide
  • Wall mount kit

*Please note that all specifications are subject to change without prior notice.

EX5510-B0 application diagram


File type Model Version Release date Language Download
Datasheet EX5510-B0 3 English
Quick Start Guide EX5510-B0 001 English
Success story EX5510-B0 1 English
Users Guide EX5510-B0 5.15 English
