4G LTE-A CBRS EUD Outdoor Router

Zyxel LTE7480-S905 4G LTE-A CBRS EUD Outdoor Router supports Cat. 16 and 3.5 GHz CBRS band by sharing their spectrums across legacy and new users. This provides your subscribers with a high–speed internet service and enables fast customer service without the reconstruction of wires.

Learn more about Zyxel CBRS Solutions >

  • Cat. 16/DL 580 Mbps
  • 4x4 MIMO 4G antennas
  • 802.3af/at PoE
  • Bridge/router
  • IP68-certified
  • Remote management
  • Zyxel mobile app
Download resources

Lightning-fast internet connectivity

The Zyxel LTE7480-S905 employs 3GPP UE downlink Category 16 – the best-practice LTE technology with downlink data rates of up to 580 Mbps through 8 spatial streams on two component carriers.

Built-in 4x4 MIMO high-gain antennas

The Zyxel LTE7480-S905 provides DL 4x4 MIMO high-gain antennas of up to 10 dBi per element for stronger and better signal from long-range transmission reach up to of 20 km. The outdoor design enables it to work under near non-line-of-sight conditions to increase coverage and capacity as well as to eliminate edge corners having difficulty accessing good signals.

Non-stop connectivity with “Dual-WAN Failover” design

The wireless LTE allows you to take advantage of the 2nd WAN without a cabling plan. As long as the gateway supports “Dual-WAN Failover ”, you can just connect Zyxel LTE7480-S905 to the existing gateway and set LTE as the failover WAN and relieve the risk of network outage.


Network setup and management in hand

Zyxel LTE7480-S905 supports Zyxel Air, an in-house developed app for Zyxel Fixed Wireless Access devices. The simple, intuitive yet powerful app simplifies the setup, configuration, and management of your customers’ home or office networks. Your technicians can provide prompt and satisfying services with reduced average service time for each customer.


Easy and flexible installation

Zyxel LTE7480-S905 comes with an 802.3af/at Gigabit PoE port and supports easy and flexible installation with a multi-way mounting kit. Your technicians can install the device with ease and accelerate the deployments.

Remote management, TR-069, HTTP/Web GUI and FTP

With TR-069, TR-181 and TR-143 support, the Zyxel LTE7480-S905 effectively secures OPEX by reducing the frequency of on-site support and by providing simplified diagnostic, configuration and troubleshooting processes.

System Specifications

IP Networking
  • Supports IPv4/IPv6 dual-stack (NDP IPv6)
  • DHCP server
  • ICMP supported
  • Virtual Private Network (VPN) passthrough
  • Supports NAT/NAPT
  • Supports DMZ
  • Supports port forwarding/triggering
  • Supports ALG
  • Supports bridge/router modes
  • Supports dynamic DNS for first APN
  • Supports remote management under bridge mode
IP Firewall
  • Firewall can be enabled or disabled via GUI
  • DoS attack detection
  • Supports SPI
  • Application-level firewall
  • Filters LAN MAC address
  • Filters LAN IP address
  • Filters URLs
  • Supports local/remote device management and firmware upgrade via TR-069 and Web GUI
  • APN management
  • PIN/PUK management
  • CLI/SSH (local and remote SSH access)
  • Supports UPNP IGD
  • Supports SSH with key access
  • Supports bandwidth/quota management
  • Supports mobile apps (iOS and Android)
  • Supports remote throughput testing (TR-143)
  • LTE Band Pilot System management compatible

Hardware Specifications

LTE Interface
  • Standard-compliant: 3GPP UE Category 16
  • Supports LTE band: 48 (CBRS) (LTE TDD 3550-3700 MHz)
  • Supports DL TM1/2/3/4/6/7/8/9
  • LTE Antennas: 4 embedded directional antennas of up to 10 dBi/element (4x4 MIMO)
  • Supports DL 2CC, 4x4 MIMO, 8 spatial streams
  • Supports DL up to 4 Carrier Aggregations, UL up to 2 Carrier Aggregations
  • Supports DL modulation QPSK, 16-QAM, 64-QAM and 256-QAM
  • Supports UL modulation QPSK, 16-QAM and 64-QAM
    • Supports DL speeds of up to 580 Mbps by TDD conf.2*
    • Supports UL speeds of up to 30.2 Mbps by TDD conf.2*
  • Max EIRP 23 dBm
Hardware Interface
  • One GbE RJ-45 PoE LAN port
  • One tri-color LED indicator for:
    • Power status
    • Internet status
    • WiFi status
  • One WiFi On/Off and WPS button
  • One 3FF Micro SIM card socket
  • One Reset & Reboot button
Power Specifications
  • IEEE 802.3af/at Power over Ethernet PD support compatible
  • Power consumption at PoE: 13 w (peak)
WiFi Interface for Management
  • 802.11 n/g/b, 2.4 GHz
  • Hidden SSID
  • 2 embedded antennas
  • For local management purpose only

Physical Specifications

  • Item dimensions (WxDxH): 254 x 255 x 58 mm (9.99" x 10.03" x 2.28")
  • Item weight: 1100 g (2.43 lb.)
  • Package dimensions (WxDxH): 420 x 280 x 108 mm (16.54" x 11.02" x 4.25")
  • Package weight: 3050 g (6.72 lb.)

Environmental Specifications

Ingress Protection Rating
  • IP68
Lightning Protection
  • K.21 enhanced mode, 6 kV
Operating Environment
  • Temperature: -40°C to 60°C (-40°F to 140°F)
  • Humidity: 5% to 95% (Non-condensing)
Storage Environment
  • Temperature: -40°C to 70°C (-40°F to 158°F)
  • Humidity: 5% to 95% (Non-condensing)


  • FCC

Package Contents

  • Gigabit PoE injector with LED indicator
  • Ethernet cable
  • Power cord
  • Cable Gland
  • Quick start guide
  • Wall/pole mounting kit

*Please note that all specifications are subject to change without prior notice.
