Advancing high-speed broadband with fixed wireless

Service providers can use the latest technology to deliver high-speed broadband services to their customers over the last mile using multiple license spectrum, or the shared-spectrum Citizens Broadband Radio Service (CBRS) over 4G and 5G LTE technology. CBRS is a band of the radio-frequency spectrum from 3.5GHz to 3.7GHz that the FCC has designated for sharing among three tiers of uses: incumbent users, priority licensees, and generally authorized, which is unlicensed. The incumbent users include satellite ground stations and the Navy.

Compared with previous mobile network technologies, 4G LTE offers much higher bandwidth (speed of data transfer), lower latency (after response times from the network), and improved spectrum efficiency (increasing overall network capacity). This allows:

More applications to be used on mobile devices, out of the home or office
Faster or real-time sharing of large files and streaming media
Near-immediate delivery of time-sensitive data, such as for real-time interaction or transactions

LTE will deliver improvements in the performance of many existing applications, and make feasible new applications that depend on reliable high-speed or responsive data transfer. Examples include innovative telemedicine applications, remote monitoring, fully mobile virtual desktops, and high-definition mobile videoconferencing. The improved user experience and practicality of LTE will also hasten the uptake of those existing applications that already work on mobile devices - but just not very well. Finally, LTE's high bandwidth can support the rapid set-up of temporary workplaces, as an alternative or backup to fixed broadband connections.

Zyxel LTE Solutions

The Zyxel LTE Series indoor and outdoor CPE enables service providers to deploy wireless broadband internet connectivity in rural and remote areas where the deployment of DSL, cable, and fiber is cost-prohibitive. The Zyxel LTE Series products support both bridge and router functions to maximize flexibility in deployment and incorporate high gain antennas for better signal performance in different deployment scenarios.

Download speeds of up to 580 Mbps*, UE cat-16, B48

Built-in 2x2 or 4x4 MIMO, high-gain antenna of up to 8 or 10 dBi per element

Standard 802.3af/at Power over Ethernet (PoE)

IP68 hardened enclosure with industrial-grade components

Embedded bridge/router mode

Remote throughput testing

Mobile apps (iOS and Android)

Zyxel outdoor LTE CPE
Our Solutions are Made to Provide Reliable Performance in Harsh Environments
Ease of Deployment and Management

Zyxel outdoor LTE CPE

Zyxel offers a range of outdoor LTE CPE that operate on CBRS or licensed frequency bands. Zyxel outdoor CPE has built-in high-gain antennas for better performance, temperature hardened enclosure, and intuitive configuration and management tools, including a mobile app.

Our Solutions are Made to Provide Reliable Performance in Harsh Environments

Designed to be easily deployed and integrated into existing network environments, LTE7461, LTE7480 and LTE7485 outdoor CPEs are housed in robust IP68 enclosures to protect them from damage from harmful dust and water when deployed in harsh outdoor environments.


Ease of Deployment and Management

Our LTE CPE is easily installed on a wall or pole and features integrated 802.3af/at PoE PD (power device) support eliminating the need to locate the device near a power source. Zyxel LTE MobileApp for Android and iOS enables service providers to set up, manage, and monitor customer CPE from a mobile device. Our LTE Series supports TR-069, remote GUI, and remote FTP to simplify remote configuration, software upgrades, and network management.


Product comparison

	INDOOR	OUTDOOR
	LTE5388 CAT16 CBRS Indoor CPE	LTE7461 Multi-licensed Band Outdoor CPE	LTE7480 CAT16 CBRS Outdoor CPE	LTE7485 CAT16 High-Power CBRS Outdoor CPE
LTE Band	B48 (B42/43)*	2/4/5/7/12/13/25/26/29/66 Certified by AT&T and Verizon	B48 (B42/43)*	B48 (B42/43)*
Category	CAT-16	CAT-6	CAT-16	CAT-16
Max DL/UL (PHY)**	580/30 Mbps (TDD Config. 2)	300/50 Mbps	580/30 Mbps (TDD Config. 2)	580/30 Mbps (TDD Config. 2)
Output power (max. TX EIRP)	23 dBm (CBRS EUD)	30 dBm	23 dBm (CBRS EUD)	36 dBm (CBSD Cat. B)
MIMO/Antenna	4x4	2x2	4x4	4x4
Operating Mode	Bridge & Router	Bridge & Router	Bridge & Router	Bridge & Router
GUI	Responsive	Responsive	Responsive	Responsive
Remote Management	TR069/TR-143 & Zyxel Band Pilot	TR069/TR-143 & Zyxel Band Pilot	TR069/TR-143 & Zyxel Band Pilot	TR069/TR-143 & Zyxel Band Pilot
Mobile App Yes	Yes	Yes	Yes	Yes
Enclosure	Indoor	IP68	IP68	IP68
Availability	Available	Available	Available	Available
Spectrum Access System (SAS) Approved	-	-	-	Certified by Commscope, Federated Wireless, and Google.

* It is for an early temporary field trial.

** The listed connection rate is the theoretical maximum. The actual data transfer rate will vary depending on the network environment.

Resources download

Datasheet

LTE Series datasheet

Competitive advantages documents

Why choose Zyxel LTE

Zyxel’s family of LTE products also includes the Citizens Broadband Radio Service (CBRS) Outdoor Router and LTE7461 Multiple-Licensed Band Outdoor Router which combine LTE network technology and high-gain antennas to provide lightning-fast Internet connectivity to hard-to-reach customers. Zyxel’s 5G products also include the 5G New Radio Sub 6GHz Outdoor router and Indoor router, which deliver greater performance, spectrum efficiency, and latency compared to current LTE standards.
