5G NR Outdoor Router
The Zyxel NR7701 5G NR Outdoor Router complies with the 3GPP Release 17 standard for competitive 5G FWA network deployments. The device delivers high-capacity, ultra-fast performance, making it a perfect choice for premium broadband services in suburban areas. Equipped with a compact form factor and a multi-type mounting kit, the NR7701 provides easy installation across a range of deployment locations.
- 5G NR, DL 4.52 Gbps
- NSA & SA modes
- 4x4 MIMO 4G/5G antennas
- TR-369/TR-471
- 802.3af/at 2.5GE PoE
- Self-installation
- IP67-certified
- Zyxel mobile app
- FOTA
Benefits
Lightning-fast internet connectivity with SA/NSA dual mode
The NR7701 supports a broad range of spectrum with 5G NR speeds up to 4.52 Gbps/730 Mbps* (DL/UL) and 4G LTE DL speeds up to 2.0 Gbps*, increasing network performance. Compliant with both Standalone (SA) and Non-Standalone (NSA) architecture, the NR7701 facilitates your deployments during 5G migration for faster service rollouts.
High-gain 4G/5G antenna for optimized signal coverage
Built-in 4x4 MIMO high-gain antennas of up to 9 dBi per element, the NR7701 can work under a near non-line-of-sight deployment scenario. With carrier aggregation, you can utilize the available spectrum resource to provide optimal signal coverage.
Environmental durability
IP67-compliant K.21 6 kV/300 A lightning protection ensures longer device life even in harsh weather or other challenging environments. The NR7701 can operate within a wide range of temperatures and humidity, whether services are deployed in urban, suburban, or rural areas close to serving base stations.
Remote management and upgrade
Through the 4G/5G radio interface, the NR7701 supports TR-369, TR-069, and remote GUI to be fully configurable. Firmware Over-The-Air (FOTA) support enables remote firmware upgrades and troubleshooting through events triggered by the operators.
Commitment to sustainability
The NR7701 is packaged in recycled paper using VOC-free vegetable oil ink, reducing waste and harmful substances, and avoiding single-use plastics and halogen materials.
Advanced power-saving mode and consumption monitoring
The NR7701’s advanced power-saving mode enables service providers to optimize energy usage and minimize waste. With seamless consumption tracking, it provides real-time and historical power insights through the Zyxel mobile app, remote management, or Web GUI. Additionally, its power monitoring** capabilities allow ISPs to generate reports that foster deeper engagement in sustainability initiatives.
Single control experience with Zyxel One apps
Zyxel One empowers end user to easily set up and manage their home network
Zyxel One
Unbox, install, and connect with Zyxel One. Supporting Wi-Fi 7 devices, the app offers an intuitive setup experience.
Zyxel One X
Zyxel One X brings the power of the cloud for smarter networking, available only through ISPs using the Zyxel One Solution.
Coming soon
Top picks from our portfolio
Solutions we also recommend
* Please note that all specifications are subject to change without prior notice.
** Power monitoring is available upon request. Please contact us for more information on availability.
Application Diagram
