5G indoor coverage
We rely on being connected through our cell phones. Yet 80% of all mobile traffic is generated indoors, notwithstanding Wi-Fi. Today, ensuring ubiquitous, uninterrupted connectivity presents significant challenges for the service providers. This includes movement within a building, which often leads to mobile signal drops that can leave subscribers dissatisfied.
The 5G-NR cellular wireless brings blazing-fast speed and high-capacity for access, the fastest 5G has more challenges for bringing cellular signal indoors by its technology essence - higher frequency, shorter coverage.
Today, millions of buildings around the world need to bring cellular signals inside. Midsized buildings, in particular, have been massively underserved. All this is growing the IBS market—fast.
IBS coverage
IBS has long since saturated highly visible public venues like airports and stadia. However, a highly functional, easily installable and affordable solution for the middle market has never appeared—until now, with Zyxel.
Products
Fiber DAS
ZoneDAS One system plays a crucial role in 5G era for businesses and consumers to solve the challenges in bringing 5G Indoors via easy-to-deploy copper or fiber cabling. ZoneDAS One supports up to 320MHz downlink in FDD mode and 400MHz downlink in 5G-NR TDD mode, making it a perfect solution for neutral host or multi-carriers co-location scenarios. With 8 Expanders, ZoneDAS One Base Unit can support up to 64 Remote Units, which can cover up to 160,000 m2 floor space.
ZoneDAS One Base Unit
- Supports up to 4 channels / bands
- Each FDD band can support up to 4 operators
- Connects up to 8 Remote Units and / or Expanders
Expander
- Adds connectivity (including power) for up to 8 more RUs
- Fiber connection can up to 2.5km
- Directly controlled by the host BU
Remote Unit
- Provides up to 2500m2 of cellular coverage
- Powered by host BU/Extender through PoE
- Easy CAT deployment, up to 100m from host Expander/BU
CAT5 DAS
Zyxel’s CAT5 DAS, ZoneDAS is simple, flexible, and highly functional. Its straightforward design has one Base Unit (BU) connecting multiple Remote Units (RU). The BU accepts multiple signal inputs, while each RU cover a zone with signal. It supports up to 4 channels/bands/operators (each 20 MHz wide, in any supported band, independent of other channels), up to 8 coverage zones (each up to 2,500m2), and full software control.
ZoneDAS Base Unit
- Supports up to 4 channels / bands / operators
- Connects up to 8 Remote Units and / or Extenders
- Great for hotels / hospitals / high-rises / shopping malls
SlimDAS Base Unit
- Supports up to 2 channels / bands / operators
- Connects up to 4 Remote Units and / or Extenders
- Great for motels / wineries / mid-rises / factories
Extender
- Adds connectivity (including power) for up to 8 more RUs
- Multiple Extenders enable up to 32 RUs for SlimDAS and 64 RUs for ZoneDAS
- Doubles RU deployment distance (to 200 meters)
- Directly controlled by the host BU
Remote Unit
- Provides up to 2500m2 of cellular coverage
- Software switchable dual-mode antennas (external-antenna versions also available)
- Powered by host BU/Extender through PoE
- Easy CAT deployment, up to 100m from host Extender/BU
MagicOffice Repeater
MagicOffice repeater is a quad-band repeater and supports coverage space up to 900 square meter. It is the best solution to extend mobile signal into small offices, café, bars, restaurants or shops. MagicOffice repeater has intuitive LED signal indicator that enables worry-free rapid installation with soft coaxial cables for system integrators, meanwhile guarantees outstanding voice and data quality for business venue owners.
SymmRepeater
Zyxel’s SymmRepeater is a revolutionary RF repeater that offers previously unattainable features and advantages through its innovative dual-device design. Notable among these is its amazing 400m zero-loss amplification range, world-leading 108 dB gain, automatic isolation detection, and patented echo-avoidance technology. And it does these at full 4G speeds, with excellent signal quality, web interface, and remote management/monitoring. And it does these at full 4G or 5G FDD speeds, with excellent signal quality, web interface, and remote management/monitoring.
Indoor Housing
- Comes in Donor or Service configurations
- Svelte, inconspicuous design
- Great for ceiling or wall installation
- Available bi-pole antennas
IP65 Housing
- Comes in Donor or Service configurations
- IP65 water/dust resistant sealed design
- Great for pole or wall installation
- Available bi-pole or patch antennas
