Nebula 5G AX3000 5G Indoor Router

Nebula FWA505v2

5G connectivity icon showing support for speeds up to 4.67Gbps.

5G - 4.67Gbps
Supports 5G speeds up to 4.67Gbps

AX3000 WiFi 6 icon showing four high-gain antennas delivering speeds up to 3Gbps.

AX3000 WiFi 6
4x WiFi 6 high-gain antennas delivering up to 1.6Gbps

Dual WAN icon showing one GbE LAN/WAN port and one GbE LAN port for failover.

Daul WAN
2x 1G LAN or 2nd WAN option for failovere

Cloud management icon showing zero-touch setup, remote monitoring and cloud-based control.

Cloud management
Zero-touch setup, remote management and monitoring

Zyxel Nebula FWA505v2 delivers up to 4.67Gbps 5G NR and AX3000 WiFi 6 with reliable 360-degree coverage for up to 64 connected devices.

Unlock multi-gigabit 5G
with intelligent connectivity.

Experience ultra-fast 5G NR speeds of up to 4.67Gbps. The FWA505v2 combines 5G and WiFi 6 AX3000 technology powered by four high-gain omni-directional antennas to deliver reliable 360-degree signal reception and fiber-class aggregate bandwidth for up to 64 connected devices. Whether connecting through its versatile gigabit ethernet ports or ultra-fast wireless, users benefit from a smooth, low-latency experience that feels just like fiber.

Built to reduce waste.
Engineered to save energy.

The FWA505v2 has been designed with sustainability in mind. Made from 95% recycled plastic and shipped in halogen-free, VOC-free packaging, the FWA505v2 meets sustainability standards without compromising performance.

Security features of Zyxel Nebula FWA505v2 including SPI firewall, DoS protection, application-level firewall, VPN pass-through and access filtering.

Multi-layered security
for reliable connectivity.

Protect your network with a robust, multi-layered security architecture designed to ensure stable and reliable connectivity. Advanced protection features help defend against common network threats while enabling secure remote access and granular traffic control for better visibility and management.


  • SPI (Stateful Packet Inspection) firewall for advanced traffic monitoring
  • DoS attack detection to help prevent service disruptions
  • LAN-to-WAN application-level firewall for enhanced network protection
  • VPN pass-through support for PPTP, IPSec and L2TP secure connections
  • MAC, IP and URL filtering for granular access control
Zyxel Nebula FWA505v2 setup and management section showing Nano SIM installation, Nebula app control and LED status indicators.

Effortless setup with
simple cloud management.

With the FWA505v2 you can achieve instant connectivity with zero wiring by simply inserting a Nano SIM card, eliminating the need for professional IT expertise. Network management is made easy with the Nebula mobile app, offering cloud-based control, remote monitoring and quick setup. Intuitive LED indicators also allow you to easily track device status at a glance.

Click. Tap. Done.

Get up and running in minutes with the Nebula mobile app. With just a few simple clicks, our user-friendly step-by-step wizard walks you through the entire installation process, no technical expertise required.


Once connected, the intuitive interface gives you complete control, making it easy to adjust settings, monitor performance and manage your network anytime, anywhere.


Search: Zyxel Nebula Mobile

Nebula mobile app
Zyxel Nebula  FWA505v2 setup made easy with the Nebula mobile app, offering step-by-step guidance, intuitive network management, and full control for WISP deployments.

Powerful, effortless and
scalable connectivity.

With Nebula, you can manage your entire network – wireless, switching, security and FWA – through a single centralized cloud platform. Deploy and configure devices quickly and remotely, without the need for extra hardware controllers or software.


Whether you're managing one site or many, Nebula delivers real-time monitoring, instant alerts and complete network visibility – anytime, anywhere.


Scale confidently, simplify operations and stay secure – all through one intuitive platform.

LED Indicators:
  • Power/System
  • WAN/Internet
  • 5G/4G Strength
  • WiFi/WPS
WPS button
Nano SIM
GbE LAN1 port
GbE LAN2/WAN port
Reset button
Power button
Power jack

* All specifications are subject to change without notice.
